Fiat Panda Workshop Manuals and Repair Manuals
Every Manual available online - found by our community and shared for FREE. Enjoy!
Fiat Panda
The Fiat Panda was introduced in 1980 and has undergone generational changes to what it is today. The first generation Fiat Panda was introduced in 1980, and was produced until 1986, when it underwent several changes. From 1986 until 2003, it was produced with only a few changes. They are now sometimes referred to as the "old Panda". The second generation was launched in 2003 and was successful winning the European car of the year (2004). The third and present generation was introduced in 2011 and is still being produced.Fiat Panda FAQ's
How do I change the air filter in my Fiat Panda?
To change the air filter in your Fiat Panda, locate the air filter housing under the hood. Unclip the housing cover and remove the old air filter. Clean the housing if necessary, then insert the new air filter and reattach the cover. Be sure to use the correct size and type of air filter for your model.
How do I change the battery in my Fiat Panda?
To change the battery in your Fiat Panda, first disconnect the negative cable from the battery terminal. Remove the battery hold-down clamp and carefully lift the battery out of the car. Install the new battery and reconnect the hold-down clamp and negative cable. Be sure to properly tighten all connections.
How do I change the brake pads in my Fiat Panda?
To change the brake pads in your Fiat Panda, first remove the wheel and locate the brake caliper. Use a wrench to remove the caliper bolts and carefully lift the caliper off the rotor. Remove the old brake pads and install the new pads, then reattach the caliper and wheel. Be sure to properly torque the caliper bolts.
How do I change the headlights in my Fiat Panda?
To change the headlights in your Fiat Panda, locate the headlight assembly under the hood. Twist the bulb socket counterclockwise to release it, then pull the bulb out of the socket. Insert the new bulb and twist the socket clockwise to secure it. Be sure to use the correct type of bulb for your model.
How do I change the spark plugs in my Fiat Panda?
To change the spark plugs in your Fiat Panda, locate the spark plug wires and follow them to the spark plugs. Use a spark plug socket and ratchet to remove the old spark plugs, then gap and install the new spark plugs. Be sure to use the correct type and size of spark plug for your engine.
How do I change the windshield wipers in my Fiat Panda?
To change the windshield wipers in your Fiat Panda, lift the wiper arm away from the windshield and rotate the blade perpendicular to the arm. Press the release tab and slide the old blade off the arm. Slide the new blade onto the arm and release the tab to secure it. Be sure to use the correct size and type of wiper blade for your model.
How do I check the oil level in my Fiat Panda?
To check the oil level in your Fiat Panda, park the car on a level surface and wait for the engine to cool down. Remove the dipstick and wipe it clean, then reinsert it and pull it out again to check the oil level. Make sure the oil level falls between the minimum and maximum marks on the dipstick.
How do I diagnose an engine misfire in my Fiat Panda?
To diagnose an engine misfire in your Fiat Panda, first check the spark plugs and wires. If they are in good condition, check the fuel injectors and ignition coils. You may also want to check the engine compression and vacuum. Consult a Fiat Panda repair manual for specific diagnostic procedures.
How do I replace the serpentine belt in my Fiat Panda?
To replace the serpentine belt in your Fiat Panda, use a wrench to release tension on the belt tensioner and slip the old belt off the pulleys. Install the new belt according to the belt routing diagram under the hood. Be sure to properly tension the belt and check for proper alignment.
How do I replace the thermostat in my Fiat Panda?
To replace the thermostat in your Fiat Panda, first remove the thermostat housing from the engine block. Remove the old thermostat and clean the housing and block mating surfaces. Install the new thermostat with the spring side facing into the engine block, then reattach the housing. Be sure to properly torque the housing bolts.
How do I replace the timing belt in my Fiat Panda?
To replace the timing belt in your Fiat Panda, first remove the accessory drive belt and timing belt cover. Align the timing marks on the camshaft and crankshaft, then release tension on the timing belt tensioner and slip the old belt off the pulleys. Install the new belt and properly tension it, then reattach the cover and accessory drive belt.
How do I replace the water pump in my Fiat Panda?
To replace the water pump in your Fiat Panda, first drain the cooling system and remove the accessory drive belt. Remove the water pump pulley and disconnect the hoses and electrical connectors from the water pump. Remove the water pump bolts and lift the pump off the engine block. Install the new water pump and reattach the pulley, hoses, and electrical connectors. Refill and bleed the cooling system.
How do I troubleshoot an electrical problem in my Fiat Panda?
To troubleshoot an electrical problem in your Fiat Panda, first check the fuses and relays. If they are in good condition, check the battery and alternator. You may also want to check the wiring and electrical connectors. Consult a Fiat Panda repair manual for specific troubleshooting procedures.
How often should I change the oil in my Fiat Panda?
The oil in your Fiat Panda should be changed every 7,500 miles or 12 months, whichever comes first. However, if you drive in severe conditions such as stop-and-go traffic or extreme temperatures, you may need to change the oil more frequently. Consult your owner's manual or a Fiat Panda repair manual for specific recommendations.
What type of oil should I use in my Fiat Panda?
The type of oil you should use in your Fiat Panda depends on the engine type and model year. Consult your owner's manual or a Fiat Panda repair manual to find out the recommended oil type and viscosity. Generally, synthetic or semi-synthetic oils with a viscosity of 5W-30 or 10W-40 are suitable for most Fiat Panda models.
Fiat Panda on Amazon
Fiat Panda Owners Manual
-
- 2007 Fiat Panda Owner Manual
- (206 Pages)
- (Free)
-
- Fiat Panda 2007 Owners Manual
- (206 Pages)
- (Free)
-
- Fiat Panda 2009 Owners Manual
- (226 Pages)
- (Free)
-
- Fiat Panda 2013 Owners Manual
- (284 Pages)
- (Free)
Fiat Panda Misc Document
- (Free)
-
- Fiat Panda 2007 Misc Documents Bluetooth
- (18 Pages)
- (Free)
- (Free)
-
- Fiat Panda 2007 Misc Documents Sound System
- (122 Pages)
- (Free)
- (Free)
- (Free)
- (Free)
- (Free)
-
- Fiat Panda 2009 Misc Documents Connect Nav
- (166 Pages)
- (Free)
- (Free)
- (Free)
- (Free)
- (Free)
- (Free)
-
- Fiat Panda 2009 Misc Documents Sound System
- (34 Pages)
- (Free)
- (Free)
-
- Fiat Panda 2013 Misc Documents Brochure
- (32 Pages)
- (Free)
-
- Fiat Panda Misc Documents Accessories
- (44 Pages)
- (Free)
- (Free)
-
- Fiat Panda Misc Documents Catalogue Italian
- (31 Pages)
- (Free)
-
- Fiat Panda Misc Documents Tech Spec
- (7 Pages)
- (Free)
