Ford S-Max
Introduced at the 2006 Geneva Motor Show, The Ford S-Max is a 5-door multipurpose vehicle or "peoplemover" from Ford Motor Company. Designed specifically for the European market, the Ford S-Max was a stylishly sporty and attractive alternative to the more utilitarian suburban minivan. The S-Max is the first vehicle in Ford's lineup to feature their Kinetic Design styling. The Kinetic Design scheme includes angular headlights, twin trapezoidal grilles, and large wheelarches. It comes with heated front and back windscreens, parking sensors, aux input, bluetooth connectivity, voice command and dual climate control as standard.Ford S-Max FAQ's
How do I change the oil in a Ford S-Max?
To change the oil in a Ford S-Max, you will need to drain the old oil from the engine using an oil drain pan. Remove the oil filter and replace it with a new one. Refill the engine with the recommended amount of new oil and start the engine to check for any leaks. It is recommended to change the oil every 5,000 miles.
How do I check the brake fluid level in a Ford S-Max?
To check the brake fluid level in a Ford S-Max, locate the brake fluid reservoir and check the level against the markings on the side. If the level is low, add the recommended type of brake fluid until it reaches the proper level. It is important to maintain the proper brake fluid level for optimal brake performance and safety.
How do I check the coolant level in a Ford S-Max?
To check the coolant level in a Ford S-Max, first make sure the engine is cool. Locate the coolant reservoir and check the level against the markings on the side. If the level is low, add a 50/50 mixture of coolant and water. It is important to maintain the proper coolant level to prevent overheating and engine damage.
How do I replace a headlight bulb in a Ford S-Max?
To replace a headlight bulb in a Ford S-Max, first remove the headlight assembly by removing the retaining clips or bolts. Disconnect the wiring harness from the back of the headlight assembly and remove the old bulb. Install a new bulb and reassemble the headlight assembly. It is recommended to replace both headlight bulbs at the same time.
How do I replace a side mirror on a Ford S-Max?
To replace a side mirror on a Ford S-Max, first remove the interior door panel to access the mirror mounting bolts. Disconnect the wiring harness from the mirror and remove the mounting bolts. Install a new mirror and reassemble the interior door panel. It is recommended to replace the mirror as soon as possible to maintain safe driving conditions.
How do I replace a taillight bulb in a Ford S-Max?
To replace a taillight bulb in a Ford S-Max, first locate the bulb holder behind the taillight assembly. Twist the holder counterclockwise to remove it and pull out the old bulb. Install a new bulb and reassemble the bulb holder. It is recommended to replace both taillight bulbs at the same time.
How do I replace the air filter in a Ford S-Max?
To replace the air filter in a Ford S-Max, locate the air filter housing and remove the air filter cover. Remove the old air filter and install a new one, making sure it fits snugly in the housing. Replace the air filter cover and secure it in place. It is recommended to replace the air filter every 15,000 miles.
How do I replace the battery in a Ford S-Max?
To replace the battery in a Ford S-Max, first disconnect the negative cable from the battery terminal. Remove the hold-down clamp and lift out the old battery. Install the new battery and secure it in place with the hold-down clamp. Reconnect the negative cable to the battery terminal. It is recommended to replace the battery every 3-5 years.
How do I replace the brake pads on a Ford S-Max?
To replace the brake pads on a Ford S-Max, first remove the wheel and the caliper bolts. Slide the caliper off the rotor and remove the old brake pads. Install the new brake pads and reassemble the caliper. It is recommended to replace the brake pads every 25,000 miles or as needed.
How do I replace the cabin air filter in a Ford S-Max?
To replace the cabin air filter in a Ford S-Max, locate the filter housing behind the glove box. Remove the old filter and install a new one, making sure it fits snugly in the housing. Replace the filter housing cover and secure it in place. It is recommended to replace the cabin air filter every 15,000 miles.
How do I replace the spark plugs in a Ford S-Max?
To replace the spark plugs in a Ford S-Max, first locate the spark plug wires and remove them from the spark plugs. Use a spark plug socket to remove the old spark plugs and install new ones. Reconnect the spark plug wires in the correct order. It is recommended to replace the spark plugs every 30,000 miles.
How do I replace the windshield wipers on a Ford S-Max?
To replace the windshield wipers on a Ford S-Max, lift the wiper arm away from the windshield and press the release tab to remove the old wiper blade. Install the new wiper blade by sliding it onto the wiper arm until it clicks into place. Lower the wiper arm back onto the windshield. It is recommended to replace the wiper blades every 6-12 months.
How do I troubleshoot a check engine light in a Ford S-Max?
To troubleshoot a check engine light in a Ford S-Max, first use an OBD-II scanner to retrieve the diagnostic trouble code (DTC). Look up the DTC in the repair manual or online to determine the cause and possible solutions. Common causes of a check engine light include a loose gas cap, faulty oxygen sensor, or catalytic converter issue.
What are the common causes of transmission failure in a Ford S-Max?
The common causes of transmission failure in a Ford S-Max include low transmission fluid, worn out clutches, and burnt transmission fluid. Low transmission fluid can cause the transmission to overheat and damage the internal components. Worn out clutches can cause the transmission to slip, resulting in poor performance and eventually leading to failure. Burnt transmission fluid can cause the transmission to overheat and damage the internal components.
What is the recommended tire pressure for a Ford S-Max?
The recommended tire pressure for a Ford S-Max varies depending on the tire size and load capacity. Refer to the owner's manual or tire information placard for the recommended tire pressure. It is important to check the tire pressure regularly and adjust it as needed for optimal performance and safety.
Ford S-Max on Amazon
Ford S-Max Owners Manual
-
- Ford S Max 2006 Owners Manual
- (312 Pages)
- (Free)
-
- Ford S Max 2011 Owners Manual
- (326 Pages)
- (Free)
-
- Ford S Max 2012 Owners Manual
- (348 Pages)
- (Free)
-
- Ford S Max 2013 Owners Manual
- (348 Pages)
- (Free)
-
- Ford S Max 2014 Owners Manual
- (348 Pages)
- (Free)
-
- Ford S Max 2015 Owners Manual
- (448 Pages)
- (Free)
