Jeep Compass Workshop Manuals and Repair Manuals

To change the cabin air filter in your Jeep Compass, start by removing the glove box by squeezing the sides to release the stops. With the glove box removed, locate the access door for the cabin air filter. Open the door and slide out the old filter. Insert the new filter, ensuring it is properly aligned, and close the access door. Reinstall the glove box by aligning the stops and gently pushing it back into place. It is recommended to consult the owner's manual for detailed instructions and specific filter types.

To change the headlights on your Jeep Compass, start by opening the hood and locating the back of the headlight assembly. Disconnect the electrical connector by pressing the release tab and pulling it off. Then, remove the retaining clips or screws securing the headlight assembly and carefully pull it out. Replace the old bulb with a new one, ensuring it is securely in place, and reassemble the headlight assembly. It is recommended to refer to the owner's manual for detailed instructions and specific bulb types.

To check the automatic transmission fluid level in your Jeep Compass, start the engine and allow it to warm up to normal operating temperature. Locate the transmission dipstick, typically labeled and located near the back of the engine bay. With the engine running, pull out the dipstick, wipe it clean, then reinsert it fully. Remove the dipstick again and check the fluid level, which should be within the designated range. If the fluid level is low, carefully add the recommended ATF+4 fluid to bring it to the proper level. It is important to use the correct type of transmission fluid as specified in the owner's manual.

To check the brake fluid level in your Jeep Compass, start by locating the brake fluid reservoir under the hood. The reservoir is typically located near the firewall on the driver's side. Ensure the vehicle is parked on a level surface, and the engine is cool. Remove the reservoir cap and visually inspect the fluid level, which should be between the minimum and maximum marks. If the fluid level is low, carefully add the recommended brake fluid to bring it to the appropriate level. It is important to use the correct type of brake fluid as specified in the owner's manual.

To jump-start your Jeep Compass, start by positioning the donor vehicle close enough to your Jeep so that the jumper cables can reach both batteries. Ensure both vehicles are turned off and the parking brakes are engaged. Connect the positive (red) cable to the positive terminal of the dead battery, then connect the other end of the positive cable to the positive terminal of the donor battery. Next, connect the negative (black) cable to the negative terminal of the donor battery, and attach the other end of the negative cable to a grounded metal surface on your Jeep, away from the battery. Start the donor vehicle, let it run for a few minutes, then attempt to start your Jeep Compass. Once it starts, carefully disconnect the jumper cables in the reverse order.

To replace the battery in your Jeep Compass, start by ensuring the ignition is off and the vehicle is in park with the parking brake engaged. Open the hood and locate the battery. Disconnect the negative (black) cable first, followed by the positive (red) cable, using a wrench or pliers if necessary. Remove any retaining brackets or covers holding the battery in place. Carefully lift out the old battery and place the new battery in the same orientation. Reattach the retaining brackets or covers, reconnect the positive cable first, followed by the negative cable, and ensure they are securely tightened.

The fuel filter in your Jeep Compass is typically located along the fuel line, either underneath the vehicle or inside the fuel tank. Replacing the fuel filter can be a complex task and may require specialized tools and knowledge. It is recommended to consult the Jeep Compass automotive repair manual or seek the assistance of a qualified technician to ensure proper replacement and avoid potential fuel system damage.

To replace the windshield wiper blades on your Jeep Compass, lift the wiper arm away from the windshield until it locks into the service position. Locate the release tab or button on the wiper blade and press or push it to release the blade from the wiper arm. Install the new wiper blade by aligning the adapter with the wiper arm and securely attaching it. Carefully lower the wiper arm back onto the windshield. It is recommended to consult the owner's manual for detailed instructions and specific wiper blade sizes.

To reset the tire pressure monitoring system in your Jeep Compass, start by ensuring that all tires are properly inflated to the recommended pressure. Then, turn the ignition to the "ON" position without starting the engine. Press and hold the TPMS reset button until the TPMS indicator light blinks three times, indicating a successful reset. This process may vary slightly depending on the model year of your Jeep Compass, so it's always best to consult the owner's manual for detailed instructions.

The engine oil in your Jeep Compass should be changed every 5,000 to 7,500 miles or approximately every six months, whichever comes first. Regular oil changes are crucial in maintaining the performance and longevity of your engine. Neglecting to change the oil at the recommended intervals can lead to decreased fuel efficiency, engine wear, and potential damage.

The engine air filter in your Jeep Compass should be replaced every 15,000 to 30,000 miles or as recommended by the manufacturer. A clean air filter is essential for proper engine performance and fuel efficiency, as it prevents dust, dirt, and debris from entering the engine. Neglecting to replace a dirty air filter can restrict airflow, leading to decreased power, increased fuel consumption, and potential engine damage.

The recommended tire pressure for your Jeep Compass can vary depending on the specific model and trim level. However, as a general guideline, the recommended tire pressure is typically around 33 PSI for all four tires. It is important to regularly check and maintain the correct tire pressure to ensure optimal handling, fuel efficiency, and tire longevity.

Your Jeep Compass requires Mopar® Antifreeze/Coolant 10 Year/150,000 Mile Formula HOAT (Hybrid Organic Additive Technology) coolant. It is important to use the specified type of coolant as it is designed to provide optimal cooling and corrosion protection for the engine. Using the wrong coolant can lead to cooling system issues, reduced performance, and potential damage to engine components.

Your Jeep Compass requires ATF+4 (Automatic Transmission Fluid) for its transmission. It is important to use the specified type of fluid as it is specifically formulated to meet the requirements of the transmission system. Using the wrong type of transmission fluid can cause shifting issues, decreased performance, and potential damage to the transmission.
