Mazda 3

The Mazda3 or Mazda 3 (known as the Mazda Axela in Japan) is a compact car manufactured in Japan by the Mazda Motor Corporation. It was introduced in 2003 as a 2004 model, replacing the Familia/323/Protegé. A performance-oriented version of the Mazda3 is marketed as the Mazdaspeed3 in North America, Mazdaspeed Axela in Japan and the Mazda3 MPS in Europe. A second generation Mazda3 for the 2010 model year was unveiled in late 2008, with the sedan premiering at the Los Angeles Auto Show and the hatchback at the Bologna Auto Show. For the 2012 model year, Mazda began offering the Mazda3 with their newly developed SkyActiv technology, including a more rigid body, a new direct injection engine, and a new 6-speed transmission.

Mazda 3 FAQ's

How do I adjust the headlights on a Mazda 3?

To adjust the headlights on a Mazda 3, park the vehicle on a level surface facing a wall or garage door. Locate the headlight adjustment screws, usually on the back of the headlight assembly. Use a screwdriver to turn the screws and adjust the vertical and horizontal alignment of the headlights. Aim the headlights so that the top of the beam is slightly below the height of the headlight centerline on the wall.

How do I change the cabin air filter in a Mazda 3?

To change the cabin air filter in a Mazda 3, locate the filter housing under the dashboard on the passenger side. Open the housing by removing the clips or screws, then take out the old filter. Clean the housing if necessary and insert the new filter, ensuring it is properly aligned. Finally, close the housing and secure it back in place.

How do I change the serpentine belt on a Mazda 3?

To change the serpentine belt on a Mazda 3, start by locating the belt tensioner, which is typically located near the top of the engine. Use a wrench or socket to rotate the tensioner and release the tension on the belt. Slide the old belt off the pulleys and carefully route the new belt following the diagram in your Mazda 3 automotive repair manual. Finally, release the tensioner to apply proper tension to the new belt.

How do I change the windshield wiper blades on a Mazda 3?

To change the windshield wiper blades on a Mazda 3, lift the wiper arm away from the windshield and locate the release tab or button where the blade connects to the arm. Press the tab or button and slide the old blade off the wiper arm. Align the new blade with the arm and push it in until it clicks into place. Finally, gently lower the wiper arm back onto the windshield.

How do I check and add coolant in a Mazda 3?

To check and add coolant in a Mazda 3, allow the engine to cool down completely. Locate the coolant reservoir, usually a translucent plastic tank near the radiator, and check the coolant level against the markings on the reservoir. If the level is low, remove the cap and add a mixture of coolant and distilled water to the recommended level. Be cautious not to open the cap when the engine is hot, as it can cause burns.

How do I replace a fuse in a Mazda 3?

To replace a fuse in a Mazda 3, locate the fuse box, which is usually found under the dashboard or in the engine compartment. Open the fuse box cover and identify the fuse that needs replacement by referring to the diagram on the cover or in your Mazda 3 automotive repair manual. Use a fuse puller or a pair of needle-nose pliers to remove the old fuse and insert a new one of the same rating. Close the fuse box cover.

How do I replace a headlight bulb on a Mazda 3?

To replace a headlight bulb on a Mazda 3, start by opening the hood and locating the back of the headlight assembly. Disconnect the electrical connector from the bulb, then twist and remove the bulb holder. Take out the old bulb and insert the new one, ensuring it is securely in place. Finally, reattach the bulb holder and reconnect the electrical connector.

How do I replace the battery in a Mazda 3 key fob?

To replace the battery in a Mazda 3 key fob, locate the small slot or indentation on the side of the key fob. Insert a small flathead screwdriver or a coin into the slot and twist gently to separate the two halves of the key fob. Remove the old battery and insert a new one of the same type and size. Finally, align the two halves of the key fob and press them together until they snap into place.

How do I replace the brake pads on a Mazda 3?

To replace the brake pads on a Mazda 3, start by loosening the lug nuts, then jack up the vehicle and remove the wheel. Next, locate the brake caliper, remove the bolts holding it in place, and carefully slide it off. Finally, remove the old brake pads from the caliper, insert the new ones, and reassemble the caliper back onto the rotor.

How do I replace the fuel filter on a Mazda 3?

To replace the fuel filter on a Mazda 3, start by relieving the fuel system pressure by disconnecting the fuel pump fuse or relay and running the engine until it stalls. Locate the fuel filter, typically along the fuel line underneath the vehicle. Use a wrench to loosen the fittings on both sides of the filter and carefully remove it. Install the new filter, ensuring the flow direction is correct, and tighten the fittings. Finally, reconnect the fuel pump fuse or relay and start the engine to verify proper fuel flow.

How do I reset the maintenance light on a Mazda 3?

To reset the maintenance light on a Mazda 3, insert the key into the ignition and turn it to the "on" position without starting the engine. Press and hold the "Trip" button on the instrument cluster until the maintenance light begins to flash. Release the button, turn off the ignition, and start the engine. The maintenance light should be reset.

How often should I change the engine air filter in a Mazda 3?

The engine air filter in a Mazda 3 should be inspected and replaced every 15,000 to 30,000 miles, depending on driving conditions and air quality. A clogged or dirty air filter can negatively impact engine performance, fuel efficiency, and overall longevity. Regular maintenance and following the recommendations in your Mazda 3 automotive repair manual will help ensure optimal air filtration.

What are the recommended tire pressures for a Mazda 3?

The recommended tire pressures for a Mazda 3 may vary based on the specific model and year. Generally, the recommended tire pressure is around 32 PSI for all four tires. However, it is essential to consult your Mazda 3 automotive repair manual or the sticker inside the driver's door jamb for the precise tire pressure specifications.

What does the check engine light indicate in a Mazda 3?

The check engine light in a Mazda 3 typically indicates a fault or issue with the vehicle's engine or emissions system. It is advised to have the vehicle diagnosed by a qualified mechanic or using an OBD-II scanner to retrieve the specific trouble code associated with the check engine light. This will help identify the problem and necessary repairs to resolve it.

What type of oil should I use in my Mazda 3?

For optimal performance, it is recommended to use a synthetic 5W-30 oil in Mazda 3 vehicles. Synthetic oils provide better lubrication, offer improved resistance to breakdown, and enhance fuel efficiency. Always refer to your specific Mazda 3 automotive repair manual for exact oil specifications and any additional recommendations.

Mazda 3 Manuals Index

Mazda 3 Workshop Manual

Mazda 3 Owners Manual

Mazda 3 Misc Document
