Mazda CX-5

The Mazda CX-5 is a compact crossover SUV produced by Mazda starting in 2012 for the 2013 model year lineup. It is Mazda's first car featuring the new KODO - Soul of Motion Design language first shown in the Shinari concept vehicle in May 2010. It is also the first vehicle featuring the company's full Skyactiv Technology suite, featuring a rigid, lightweight platform, combined with a new series of efficient engines and transmissions resulting in reduced emissions and fuel consumption. The facelift model Mazda CX-5 was unveiled at the 2014 Los Angeles Auto Show as a 2016 model.

Mazda CX-5 FAQ's

How do I change the engine air filter in my Mazda CX-5?

To change the engine air filter in your Mazda CX-5, open the hood and locate the air filter housing. Unclip or unscrew the housing cover, remove the old air filter, and clean any debris from the housing. Install the new air filter, ensuring it is properly seated, and reattach the housing cover. It is recommended to consult your Mazda CX-5 automotive repair manual for detailed instructions and diagrams specific to your vehicle.

How do I check the coolant level in my Mazda CX-5?

To check the coolant level in your Mazda CX-5, park the vehicle on a level surface and wait until the engine is cool. Locate the coolant reservoir, typically located near the radiator. The reservoir will have minimum and maximum level markings. If the coolant level is below the minimum mark, add a mixture of coolant and distilled water to bring it to the appropriate level. Refer to your Mazda CX-5 automotive repair manual for additional guidance.

How do I diagnose and fix an engine misfire issue in my Mazda CX-5?

If your Mazda CX-5 is experiencing an engine misfire, there are a few common causes to consider. Check the ignition system, including spark plugs, ignition coils, and wiring, as well as the fuel system, such as fuel injectors and fuel pressure. Additionally, inspect the air intake system and vacuum hoses for any leaks or blockages. It is recommended to refer to your Mazda CX-5 automotive repair manual for specific diagnostic procedures and troubleshooting charts to pinpoint the exact cause of the engine misfire.

How do I replace a burnt-out headlight bulb in my Mazda CX-5?

To replace a burnt-out headlight bulb in your Mazda CX-5, open the hood and locate the back of the headlight assembly. Twist and remove the bulb socket, then pull out the old bulb and insert the new one. Make sure the bulb is properly aligned and secure before reattaching the socket. Refer to your Mazda CX-5 automotive repair manual for specific instructions on replacing headlight bulbs and any additional precautions.

How do I replace a damaged side mirror on my Mazda CX-5?

To replace a damaged side mirror on your Mazda CX-5, first, remove the interior door panel to access the mirror mounting bolts. Disconnect the electrical connector and unbolt the damaged side mirror. Install the new side mirror, reconnect the electrical connector, and secure it with the mounting bolts. Finally, reattach the interior door panel. For detailed step-by-step instructions and diagrams, consult your Mazda CX-5 automotive repair manual.

How do I replace a faulty ignition coil in my Mazda CX-5?

To replace a faulty ignition coil in your Mazda CX-5, first, locate the ignition coils, typically positioned on top of the engine. Disconnect the electrical connector, unbolt the ignition coil, and remove it from the spark plug. Install the new ignition coil, ensuring it is securely in place, and reconnect the electrical connector. Repeat the process for any additional faulty ignition coils. Refer to your Mazda CX-5 automotive repair manual for detailed instructions and precautions.

How do I replace the brake pads on my Mazda CX-5?

To replace the brake pads on your Mazda CX-5, first, ensure the vehicle is safely lifted and the wheels are removed. Then, unbolt the caliper, remove the old brake pads, and use a brake piston tool to compress the caliper piston. Install the new brake pads, reattach the caliper, and repeat the process for the other wheels. Refer to your Mazda CX-5 automotive repair manual for detailed step-by-step instructions and safety precautions.

How do I reset the maintenance light on my Mazda CX-5?

To reset the maintenance light on your Mazda CX-5, turn on the ignition without starting the engine. Press and hold the trip meter reset button until the maintenance light starts flashing, then release the button. Turn off the ignition, and when you start the vehicle again, the maintenance light should be reset. For detailed instructions and variations based on different Mazda CX-5 models, consult your automotive repair manual.

How do I troubleshoot a malfunctioning air conditioning system in my Mazda CX-5?

If your Mazda CX-5's air conditioning system is not functioning properly, there are a few steps you can take to troubleshoot the issue. First, check the fuse and relay associated with the air conditioning system. If they are in working order, inspect the compressor clutch, condenser, and refrigerant levels. It is recommended to refer to your Mazda CX-5 automotive repair manual for detailed diagrams, troubleshooting charts, and step-by-step instructions to diagnose and repair the specific issue.

How often should I change the engine oil in my Mazda CX-5?

It is recommended to change the engine oil in your Mazda CX-5 every 5,000 to 7,500 miles or every 6 months, whichever comes first. Regular oil changes help maintain engine performance and prolong the life of your vehicle. Be sure to consult your Mazda CX-5 automotive repair manual for specific instructions and recommendations.

How often should I replace the cabin air filter in my Mazda CX-5?

The cabin air filter in your Mazda CX-5 should be replaced every 12,000 to 15,000 miles or once a year, depending on driving conditions and air quality. A clean cabin air filter ensures proper air flow and keeps the interior air clean from dust, pollen, and other contaminants. Refer to your Mazda CX-5 automotive repair manual for specific instructions on how to replace the cabin air filter.

What is the recommended interval for replacing the timing belt in my Mazda CX-5?

The timing belt in your Mazda CX-5 should generally be replaced every 60,000 to 100,000 miles, depending on the model and engine type. It is crucial to follow the manufacturer's recommendations regarding timing belt replacement to prevent potential engine damage. Consult your Mazda CX-5 automotive repair manual for the specific interval and instructions for replacing the timing belt in your vehicle.

What is the recommended tire pressure for my Mazda CX-5?

The recommended tire pressure for your Mazda CX-5 can vary depending on the model and tire size. Generally, the recommended tire pressure ranges from 32 to 36 psi. It is important to regularly check and adjust the tire pressure to ensure optimal handling, fuel efficiency, and tire longevity. Consult your Mazda CX-5 automotive repair manual or the sticker located on the driver's side door jamb for the specific recommended tire pressure for your vehicle.

What type of transmission fluid should I use in my Mazda CX-5?

For optimal performance, it is recommended to use Mazda Genuine ATF FZ transmission fluid in your Mazda CX-5. This specific type of fluid is formulated to meet the requirements of the SKYACTIV-Drive automatic transmission. Following the manufacturer's recommendations ensures proper lubrication and smooth shifting.

Mazda CX-5 Manuals Index

Mazda CX-5 Workshop Manual

Mazda CX-5 Owners Manual

Mazda CX-5 Misc Document
