Mazda E series
The Mazda Bongo, also known as Mazda E-Series, is a van manufactured by the Japanese manufacturer Mazda since 1966. It has been built with rear-, middle-, as well as front-mounted engines. It also formed the basis for the long running Kia Bongo range. Mazda introduced its small van, the Bongo, in May 1966. It featured a rear-mounted 782 cc water-cooled OHV SA 4-stroke engine driving the rear wheels. The original version has round headlights and no grille; after a facelift the second generation Bongo/E-series had rectangular headlights and a more traditional grille. It was manufactured with both diesel and petrol engines.Mazda E series FAQ's
How do I change the oil in my Mazda E series?
To change the oil in your Mazda E series, start by removing the oil drain plug and letting the old oil drain out completely. Then, replace the drain plug and remove the oil filter. Install a new oil filter and refill the engine with the recommended amount of fresh oil. Be sure to dispose of the old oil and filter properly.
How do I check the battery in my Mazda E series?
To check the battery in your Mazda E series, start by turning off all electrical accessories and the engine. Open the hood and locate the battery. Check the battery terminals for any signs of corrosion or loose connections. Use a multimeter set to the DC voltage setting and connect the positive (red) probe to the positive terminal and the negative (black) probe to the negative terminal. A healthy battery should read around 12.6 volts or higher. If the voltage is significantly lower, the battery may need to be recharged or replaced.
How do I check the transmission fluid in my Mazda E series?
To check the transmission fluid in your Mazda E series, park the vehicle on a level surface and ensure the engine is warm. Locate the transmission dipstick, usually labeled with a yellow or red handle, and pull it out. Wipe the dipstick clean, reinsert it fully, and then pull it out again. The fluid level should be between the "Full" and "Add" marks on the dipstick. If it is low, add the recommended transmission fluid through the dipstick tube.
How do I replace a blown fuse in my Mazda E series?
To replace a blown fuse in your Mazda E series, locate the fuse box, usually located in the engine compartment or under the dashboard. Refer to the owner's manual or the fuse box cover to identify the specific fuse that needs to be replaced. Use a fuse puller or a pair of needle-nose pliers to carefully remove the blown fuse and replace it with a new fuse of the same amperage rating. Make sure to dispose of the old fuse properly.
How do I replace a headlight bulb in my Mazda E series?
To replace a headlight bulb in your Mazda E series, open the hood and locate the back of the headlight assembly. Depending on the specific model, you may need to remove a protective cover or unplug a wiring harness. Carefully remove the old bulb by twisting it counterclockwise and replace it with a new bulb of the same type. Make sure the bulb is securely in place and reconnect any wiring or covers that were removed.
How do I replace a serpentine belt in my Mazda E series?
To replace a serpentine belt in your Mazda E series, start by locating the belt routing diagram, usually found under the hood or in the owner's manual. Use a wrench or a belt tensioner tool to relieve tension on the belt, then carefully slide it off the pulleys. Install the new belt following the correct routing as indicated by the diagram. Double-check that the belt is properly seated on all pulleys before releasing the tensioner.
How do I replace the cabin air filter in my Mazda E series?
To replace the cabin air filter in your Mazda E series, start by locating the cabin air filter housing, which is usually located behind the glove compartment. Remove the glove compartment by releasing any retaining clips or screws. Open the cabin air filter housing and slide out the old filter. Insert the new filter, making sure it is properly aligned, and close the housing. Reinstall the glove compartment and ensure it is securely in place.
How do I reset the maintenance light on my Mazda E series?
To reset the maintenance light on your Mazda E series, turn the ignition switch to the "ON" position without starting the engine. Within three seconds, press and hold the trip meter reset knob until the maintenance light starts flashing. Release the knob, then press and hold it again until the maintenance light turns off. The light should now be reset, indicating that the maintenance reminder has been cleared.
How often should I replace the air filter in my Mazda E series?
The air filter in your Mazda E series should be replaced every 15,000 to 30,000 miles or as recommended by the manufacturer. However, if you frequently drive in dusty or dirty conditions, it is advisable to check the air filter more often and replace it if it appears clogged or dirty. A clean air filter ensures proper air flow to the engine, improving fuel efficiency and prolonging the life of the engine.
What is the recommended interval for changing the timing belt in my Mazda E series?
The recommended interval for changing the timing belt in your Mazda E series can vary depending on the specific model and engine. Generally, it is recommended to replace the timing belt every 60,000 to 100,000 miles or every 5 to 7 years, whichever comes first. Failure to replace a worn or damaged timing belt can result in severe engine damage, so it is essential to follow the manufacturer's recommendations.
What is the recommended tire pressure for my Mazda E series?
The recommended tire pressure for your Mazda E series can be found in the owner's manual or on a sticker located on the driver's side door jamb. It is important to maintain the correct tire pressure for optimal handling, fuel efficiency, and tire life. Make sure to check the tire pressure regularly, especially before long trips, and adjust it as needed using a reliable tire pressure gauge.
What should I do if my Mazda E series is overheating?
If your Mazda E series is overheating, it is important to take immediate action to prevent engine damage. Safely pull over to the side of the road and turn off the engine. Allow the engine to cool down before attempting any further diagnosis or repairs. Check the coolant level, radiator hoses, and the radiator itself for any signs of leaks or blockages. If necessary, have the vehicle towed to a qualified mechanic for further inspection and repairs.
What should I do if my Mazda E series won't start?
If your Mazda E series won't start, there are several potential causes to consider. Check the battery connections to ensure they are clean and tight. If the battery is weak or dead, try jump-starting the vehicle or replacing the battery. Check the fuel level and ensure you have enough fuel. If the engine cranks but doesn't start, there may be an issue with the ignition system or fuel delivery, and it is recommended to have the vehicle diagnosed by a professional.
What type of brake fluid should I use in my Mazda E series?
For your Mazda E series, it is recommended to use a DOT 3 or DOT 4 brake fluid. These types of brake fluids are compatible with the braking system components and provide the necessary performance and protection against corrosion. Avoid mixing different types of brake fluids and always use a fresh, sealed container to prevent contamination. Remember to check the brake fluid level regularly and top it up if needed.
What type of coolant should I use in my Mazda E series?
For your Mazda E series, it is recommended to use a high-quality, ethylene glycol-based coolant with a mixture of 50% coolant and 50% distilled water. This coolant should be specifically formulated for use in aluminum engines to provide optimal performance and protection against rust, corrosion, and overheating. Always refer to your owner's manual for the exact coolant specifications.
Mazda E series Manuals Index
Mazda E series on Amazon
Mazda E series Workshop Manual
- (Free)
Mazda E series Misc Document
-
- Mazda E series Mic Documents Brochure
- (2 Pages)
- (Free)
