Mitsubishi Carisma
The Mitsubishi Carisma is large family car produced by Japanese manufacturer Mitsubishi for European market between 1995 and 2004. It was codeveloped with Volvo and is based on first generation Volvo S-40 chassis. It was available as a four-door saloon or a five-door hatchback style and produced for the European market. In spite of its name, the Carisma had a fairly neutral design as a result of being Mitsubishi's first attempt to target the traditionally conservative European company car market. During its 9 years production run, over 350,000 units were produced.Mitsubishi Carisma FAQ's
How do I adjust the headlights on my Mitsubishi Carisma?
To adjust the headlights on your Mitsubishi Carisma, park the vehicle on a level surface facing a wall or garage door. Measure the height from the ground to the center of the headlights and mark this measurement on the wall. Back the car up about 25 feet and turn on the headlights. Using a screwdriver or a wrench, locate the adjustment screws on the headlight assembly and adjust them until the light beams align with the marks on the wall. Repeat the process for both headlights, ensuring they are properly aligned and not aimed too high or too low.
How do I change the oil in my Mitsubishi Carisma?
To change the oil in your Mitsubishi Carisma, first, ensure the engine is cool and the vehicle is on level ground. Locate the oil drain plug underneath the car and place an oil pan beneath it. Loosen the drain plug and allow the old oil to drain completely. Once drained, replace the drain plug, remove the oil filter, and install a new one. Finally, refill the engine with the recommended amount of fresh oil.
How do I check the tire pressure on my Mitsubishi Carisma?
To check the tire pressure on your Mitsubishi Carisma, start by ensuring the tires are cool. Locate the valve stem on each tire and remove the valve cap. Use a tire pressure gauge to measure the pressure by placing the gauge over the valve stem and pressing firmly. The gauge will display the tire pressure, and you can compare it to the recommended pressure listed in the owner's manual or on a sticker inside the driver's door frame. If the pressure is low, add air until it reaches the proper level.
How do I check the transmission fluid level in my Mitsubishi Carisma?
To check the transmission fluid level in your Mitsubishi Carisma, ensure the vehicle is on level ground and the engine is running. Locate the transmission dipstick, which is usually near the back of the engine bay. Pull out the dipstick, wipe it clean, and reinsert it fully. Withdraw the dipstick again and observe the fluid level. The fluid should be within the recommended range indicated on the dipstick. If it is low, add the appropriate transmission fluid until it reaches the correct level.
How do I replace a blown fuse in my Mitsubishi Carisma?
To replace a blown fuse in your Mitsubishi Carisma, first, locate the fuse box, which is usually located in the engine compartment or under the dashboard. Open the fuse box and refer to the diagram on the inside cover or in the owner's manual to identify the specific fuse associated with the malfunctioning circuit. Use a fuse puller or a pair of needle-nose pliers to gently pull out the blown fuse. Replace it with a new fuse of the same amperage rating and push it firmly into place. Close the fuse box and test the circuit to ensure it is functioning properly.
How do I replace a headlight bulb on my Mitsubishi Carisma?
To replace a headlight bulb on your Mitsubishi Carisma, start by opening the hood. Locate the back of the headlight assembly and disconnect the electrical connector from the bulb. Depending on the model year, you may need to remove a rubber cover or a retaining clip to access the bulb. Once exposed, twist the bulb counterclockwise and remove it from the socket. Insert the new bulb, ensuring it is securely seated, and reassemble the components in reverse order. Finally, test the headlight to ensure proper functionality.
How do I replace the brake pads on my Mitsubishi Carisma?
To replace the brake pads on your Mitsubishi Carisma, start by safely lifting the vehicle and removing the wheel. Locate the brake caliper and remove the bolts securing it. Carefully remove the caliper, ensuring not to damage the brake line. Next, remove the old brake pads and replace them with new ones. Before reattaching the caliper, compress the piston using a C-clamp or brake piston tool. Finally, reinstall the caliper, tighten the bolts, and repeat the process for the remaining wheels.
How do I replace the windshield wipers on my Mitsubishi Carisma?
To replace the windshield wipers on your Mitsubishi Carisma, start by lifting the wiper arm away from the windshield. Locate the release tab or button on the wiper blade assembly and press it to release the old blade. Slide the blade out of the assembly. Align the new wiper blade with the arm and insert it into the assembly until it clicks into place. Lower the wiper arm back onto the windshield and repeat the process for the other wiper blade. It is recommended to replace wiper blades annually or when they show signs of deterioration or poor performance.
How do I reset the maintenance light on my Mitsubishi Carisma?
To reset the maintenance light on your Mitsubishi Carisma, turn the ignition switch to the "ON" position without starting the engine. Press and hold the odometer reset button until the maintenance light starts flashing. Release the button, turn off the ignition, and then start the engine. The maintenance light should no longer be illuminated. It is important to note that the specific procedure may vary depending on the model year of your Carisma, so consulting the owner's manual for the correct reset procedure is recommended.
How do I troubleshoot a malfunctioning power window in my Mitsubishi Carisma?
If you are experiencing issues with a malfunctioning power window in your Mitsubishi Carisma, start by checking the window switch for any visible damage or debris. Clean the switch and try operating the window again. If the window still doesn't work, check the fuse related to the power windows in the fuse box. If the fuse is blown, replace it with a new one of the same amperage rating. If the fuse is intact
How often should I replace the air filter in my Mitsubishi Carisma?
The air filter in your Mitsubishi Carisma should be replaced regularly to ensure proper engine performance and fuel efficiency. As a general guideline, it is recommended to replace the air filter every 12,000 to 15,000 miles or as specified in the owner's manual. However, if you frequently drive in dusty or polluted environments, it may be necessary to replace the air filter more frequently. A clogged or dirty air filter can restrict airflow to the engine, leading to decreased performance and increased fuel consumption.
How often should I replace the spark plugs in my Mitsubishi Carisma?
The spark plugs in your Mitsubishi Carisma should be replaced according to the manufacturer's recommended maintenance schedule. Typically, spark plugs should be replaced every 30,000 to 60,000 miles, but this can vary depending on driving conditions and the type of spark plugs used. It is important not to neglect spark plug replacement, as worn-out spark plugs can lead to poor engine performance, misfires, and reduced fuel efficiency.
What should I do if my Mitsubishi Carisma is overheating?
If your Mitsubishi Carisma is overheating, the first step is to safely pull over and turn off the engine. Allow the engine to cool down before opening the hood. Check the coolant level and make sure it is at the recommended level. If the coolant level is low, you may need to add more coolant. Additionally, inspect the radiator for any signs of leaks or blockages. If the issue persists, it is recommended to consult a professional mechanic for further diagnosis.
What should I do if my Mitsubishi Carisma won't start?
If your Mitsubishi Carisma won't start, there are a few potential causes to consider. First, check the battery connections and ensure they are clean and securely attached. If the battery is weak or dead, jump-start the vehicle or replace the battery if necessary. Next, inspect the fuel level and ensure there is enough fuel in the tank. If the fuel level is fine, it could be a problem with the ignition system, such as a faulty ignition switch or a bad starter motor. In such cases, it is advisable to seek professional assistance for diagnosis and repair.
What type of engine oil should I use for my Mitsubishi Carisma?
For optimal performance, it is recommended to use the engine oil specified in the Mitsubishi Carisma owner's manual. The manual will provide the recommended viscosity grade and oil specification required for your specific model of the Carisma. Using the correct engine oil is crucial to maintain proper lubrication and protect the engine components, ensuring longevity and performance.
Mitsubishi Carisma Manuals Index
Mitsubishi Carisma on Amazon
Mitsubishi Carisma Workshop Manual
-
- Mitsubishi Carisma 1996 Workshop Manual
- (87 Pages)
- (Free)
-
- Mitsubishi Carisma 1996 Workshop Manual 2
- (959 Pages)
- (Free)
-
- Mitsubishi Carisma 1997 Workshop Manual
- (57 Pages)
- (Free)
-
- Mitsubishi Carisma 1997 Workshop Manual (2)
- (288 Pages)
- (Free)
-
- Mitsubishi Carisma 1999 2000 Workshop Manual
- (396 Pages)
- (Free)
Mitsubishi Carisma Owners Manual
-
- Mitsubishi Carisma Owners Manual Czech
- (258 Pages)
- (Free)
Mitsubishi Carisma Misc Document
- (Free)
- (Free)
- (Free)
-
- Mitsubishi Carisma 1998 Misc. Document Electrical Wiring
- (1,129 Pages)
- (Free)
- (Free)
- (Free)
- (Free)
- (Free)
- (Free)
- (Free)
- (Free)
