Nissan Note
Unveiled at Paris Motors Show in 2004, the Nissan Note is a mini MPV (Multi-Purpose Vehicle) from Japanese manufacturer Nissan. This 5-door hatchback has intelligent key with proximity sensor, arched roof line, boomerang LED rear lights, doubledeck four-slot grille, 17 inch alloy wheels, sports seats, an aluminium display with satellite navigation, brushed aluminium interior fittings, dark grey exterior body colour, perforated 'metallic' black and silver leather upholstery, climate control and many other premium features. Japan model went on sale in 2005-01-20. Early Nissan Note models include 15RX, 15E, 15S, 15S V-package, 15E FOUR, 15S FOUR, 15S FOUR V-package. Early Nissan Note Rider models include 15S, 15S V-package, 15S FOUR, 15S FOUR V-package. Early Note Lifecare Vehicles include Enchante (Slide-out Lift Front Passenger's Seat) (15E, 15S, 15E FOUR, 15S FOUR), Enchante (Swivel Front Passenger's Seat) (15S, 15S FOUR), Driving Helper with Autech Driving Control Package Type e (15S, 15S FOUR).Nissan Note FAQ's
How do I change the oil in a Nissan Note?
To change the oil in a Nissan Note, start by locating the oil drain plug underneath the vehicle and place a drain pan beneath it. Remove the drain plug and allow the old oil to fully drain out. Once drained, replace the drain plug and proceed to remove the oil filter. Install a new oil filter and then refill the engine with the recommended amount and type of oil specified in the manual. Be sure to check the oil level after running the engine for a few minutes and top up if necessary.
How do I check the transmission fluid level in a Nissan Note?
To check the transmission fluid level in a Nissan Note, start by parking the vehicle on a level surface and ensuring the engine is at operating temperature. Locate the transmission dipstick, typically labeled and located near the back of the engine bay. Remove the dipstick, wipe it clean with a cloth, and reinsert it fully. Remove the dipstick again and check the fluid level. It should be within the designated range marked on the dipstick. If the level is low, add the recommended transmission fluid through the dipstick tube, taking care not to overfill.
How do I jump-start a Nissan Note?
To jump-start a Nissan Note, you will need a set of jumper cables and another vehicle with a charged battery. Park both vehicles close to each other but do not let them touch. Connect one end of the red (positive) jumper cable to the positive terminal of the dead battery, then connect the other end to the positive terminal of the charged battery. Connect one end of the black (negative) jumper cable to the negative terminal of the charged battery, and the other end to a metal part of the engine block or vehicle frame of the dead battery. Start the vehicle with the charged battery and let it run for a few minutes, then attempt to start the Nissan Note.
How do I replace a brake light bulb in a Nissan Note?
To replace a brake light bulb in a Nissan Note, start by opening the trunk and locating the bulb housing behind the brake light lens. Twist the bulb socket counterclockwise to unlock it and gently pull it out. Remove the old bulb by pulling it straight out and insert the new bulb. Ensure it is securely seated in the socket. Reinsert the bulb socket into the housing and twist it clockwise to lock it in place. Test the brake light to ensure it is functioning properly.
How do I replace a cabin air filter in a Nissan Note?
To replace a cabin air filter in a Nissan Note, start by locating the cabin air filter housing, which is usually behind the glove compartment. Open the glove compartment and remove any contents. Release the retaining clips or screws that hold the housing cover in place and remove the cover. Take out the old filter by sliding it out of the housing and replace it with a new filter. Reinstall the housing cover and secure it with the retaining clips or screws. Close the glove compartment.
How do I replace a fuel filter in a Nissan Note?
To replace a fuel filter in a Nissan Note, start by relieving the fuel system pressure by removing the fuel pump fuse or relay and cranking the engine until it stalls. Locate the fuel filter, typically located along the fuel line under the vehicle. Place a drain pan beneath the filter to catch any fuel spills. Disconnect the fuel lines from the filter using a suitable tool and remove the mounting bracket or clamp holding the filter in place. Install the new filter in the reverse order, ensuring the fuel lines are securely connected and the filter is properly mounted.
How do I replace a headlight bulb in a Nissan Note?
To replace a headlight bulb in a Nissan Note, start by opening the hood and locating the back of the headlight assembly. Remove the electrical connector from the bulb by pressing the release tab and gently pulling it off. Twist the bulb counterclockwise to remove it from the socket, then insert the new bulb and twist it clockwise to secure it. Reconnect the electrical connector and test the headlight to ensure it is working properly.
How do I replace a serpentine belt in a Nissan Note?
To replace a serpentine belt in a Nissan Note, start by locating the belt routing diagram, typically found on a decal in the engine bay. Using a wrench or belt tensioner tool, rotate the tensioner pulley counterclockwise to relieve tension on the belt. Slide the old belt off the pulleys, making note of the routing. Install the new belt following the belt routing diagram and ensure it is properly seated on each pulley. Rotate the tensioner pulley counterclockwise again and slide the new belt onto it. Release the tensioner to apply tension to the belt.
How do I replace a thermostat in a Nissan Note?
To replace a thermostat in a Nissan Note, start by allowing the engine to cool down completely. Locate the thermostat housing, typically located near the engine block and connected to the upper radiator hose. Drain some coolant from the radiator to relieve pressure, then disconnect the upper radiator hose from the thermostat housing. Remove the bolts securing the thermostat housing and carefully lift off the housing to access the thermostat. Replace the old thermostat with a new one, ensuring it is properly seated. Reassemble the housing, reconnect the upper radiator hose, and refill the cooling system with the recommended coolant.
How do I replace a windshield wiper blade in a Nissan Note?
To replace a windshield wiper blade in a Nissan Note, start by lifting the wiper arm away from the windshield. Locate the release clip or tab on the wiper blade assembly and press or slide it to release the blade. Slide the old blade out of the assembly and slide the new blade in until it clicks into place. Carefully lower the wiper arm back onto the windshield. Repeat the process for the other wiper blade, if necessary.
How do I replace the battery in a Nissan Note?
To replace the battery in a Nissan Note, start by turning off the vehicle and ensuring the engine is cool. Locate the battery, typically located in the engine bay or trunk. Disconnect the negative (-) terminal first by loosening the clamp and lifting it off the battery post. Repeat the same process for the positive (+) terminal. Remove any retaining brackets or clamps holding the battery in place and carefully lift it out. Install the new battery in the reverse order, reconnecting the positive terminal first followed by the negative terminal.
How do I reset the maintenance light on a Nissan Note?
To reset the maintenance light on a Nissan Note, turn the ignition switch to the ON position without starting the engine. Within 10 seconds, fully depress and release the accelerator pedal five times. Wait for about 10 seconds until the service engine soon light starts flashing, indicating that the reset is complete. Turn the ignition switch to the OFF position and then start the engine to ensure the maintenance light no longer appears.
How do I troubleshoot a starting issue in a Nissan Note?
If you are experiencing a starting issue in a Nissan Note, there are a few troubleshooting steps you can take. First, check the battery connections and ensure they are clean and secure. If the connections are fine, try jump-starting the vehicle to see if the issue is related to a weak battery. If the vehicle still doesn't start, check the starter motor and ignition system for any potential issues. It may be necessary to consult the repair manual or seek professional assistance to diagnose and resolve the starting issue.
How often should I change the air filter in a Nissan Note?
The air filter in a Nissan Note should be inspected and replaced, if necessary, every 12,000 to 15,000 miles or as specified in the owner's manual. A clogged or dirty air filter can restrict airflow to the engine, leading to reduced performance and fuel efficiency. Regularly checking and replacing the air filter will help maintain the vehicle's optimal performance.
What is the recommended tire pressure for a Nissan Note?
The recommended tire pressure for a Nissan Note can be found in the owner's manual or on a decal located on the driver's door jamb. It is important to maintain the correct tire pressure for optimal performance, fuel efficiency, and safety. Underinflated tires can lead to poor handling and increased tire wear, while overinflated tires can negatively impact ride comfort and traction.
Nissan Note on Amazon
Nissan Note Workshop Manual
-
- Nissan Note 2006 Workshop Manual
- (4,711 Pages)
- (Free)
Nissan Note Owners Manual
-
- Nissan Note 2014 Owners Manual Japanese
- (274 Pages)
- (Free)
